Shelly Plus RGBW
kr. 5.250
RGBW LED borðastýring frá Shelly. Athugið að það þarf 12/24 V Led driver til að fæða eininguna (Ekki nauðsynlegt að Led driverinn sé dimmanlegur RGBW einingin sér um dimminguna)
Gerðu LED borðann snjallan með þessari einingu og stýrðu honum með fría Shelly Smart control appinu.
Á lager
Loading...
Lýsing
RGBW LED borðastýring frá Shelly. Athugið að það þarf 12/24 V Led driver til að fæða eininguna (Ekki nauðsynlegt að Led driverinn sé dimmanlegur RGBW einingin sér um dimminguna)
Gerðu LED borðann snjallan með þessari einingu og stýrðu honum með fría Shelly Smart control appinu.
| Quantity | Value |
|---|---|
| Physical | |
| Size (HxWxD): | 42x37x12 ±0.5 mm / 1.65×1.46×0.66 ±0.02 in |
| Weight: | 17 g / 0.60 oz |
| Screw terminals max torque: | 0.2 Nm / 1.8 lbin |
| Conductor cross section: | 0.1 to 1 mm² / 30 to 16 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length: | 6 mm / 0.24 in |
| Mounting: | In-wall |
| Shell material: | Plastic |
| Shell color: | Yellow |
| Connectors color: | Green |
| Environmental | |
| Ambient working temperature: | -20 °C to 40 °C / -5 °F to 105 °F |
| Humidity: | 30 % to 70 % RH |
| Electrical | |
| Power supply: | 12/24 VDC |
| Power consumption: | < 1.2 W |
| Output circuits ratings | |
| Max. control voltage: | 24 VDC |
| Max. control current: | 4 A per channel (10 A total) |
| PWM frequency | 22 kHz |
| Sensors, meters | |
| Voltmeter: | 0-24 V |
| Voltmeter accuracy: | ± 5% |
| Ammeter: | 0-10 A |
| Ammeter accuracy: | ± 10% |
| Power and energy meters: | Power measurement |
| No load threshold: | 0.5 VA per channel |
| Internal-temperature sensor: | Yes |
| Radio | |
| Wi-Fi | |
| Protocol: | 802.11 b/g/n |
| RF band: | 2401 – 2495 МHz |
| Max. RF power: | < 20 dBm |
| Range: | Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth | |
| Protocol: | 4.2 |
| RF band: | 2400 – 2483.5 MHz |
| Max. RF power: | < 4 dBm |
| Range: | Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| Microcontroller unit | |
| CPU: | ESP-Shelly C38F |
| Clock frequency: | 160 Mhz |
| RAM: | 400 KB |
| Flash: | 4 MB |
| Firmware capabilities | |
| Schedules: | 20 |
| Webhooks (URL actions): | 20 with 5 URLs per hook |
| Scripting: | Yes |
| MQTT: | Yes |
| Scripting: | Yes |
