PHYSICAL | |
---|---|
Size (HxWxD): | 94x19x69 ±0.5 mm / 3.70×0.75×2.71 ±0.02 in |
Weight: | 62 ±1 g / 2.19 ±0.05 oz |
Mounting: | DIN rail |
Screw terminals max torque: | 0.4 Nm / 4.43 lbin |
Conductor cross section: | 0.5 to 2.5 mm² / 20 to 14 AWG (solid, stranded, and bootlace lugs) |
Conductor stripped length: | 6 to 7 mm / 0.24 to 0.28 in |
Shell material: | Plastic |
Color: | White |
ENVIRONMENTAL | |
Ambient temperature: | -20 °C to 40 °C / -5 °F to 105 °F |
Humidity: | 30 % to 70 % RH |
Max. altitude: | 2000 m / 6562 ft |
ELECTRICAL | |
Power supply voltage AC: | 110 – 240 V, 50/60 Hz |
Power supply voltage DC: | N/A |
Power consumption: | < 3 W |
Sensors, meters | |
Temperature sensor: | Yes |
Voltmeters (RMS for each phase): | 100 – 260 V |
Voltmeters accuracy: | ±1 % |
Ammeters (RMS via CT for each phase and the Neutral): | 0 – 120 A |
Ammeters accuracy: | ±1 % (2 – 120 A), ±2 % (1 – 2 A), ±5 % (0 – 1 A) |
Power and energy meters: | Active and apparent power, Active and apparent energy, Power factor, Fundamental active and fundamental reactive energy |
No load threshold: | 30 VA per phase |
Measurement data storage: | At least 60 days of 1 min data resolution |
Data export: | CSV for PQ recorded values JSON format export through RPC |
RADIO | |
RF band: | 2400 – 2495 MHz |
Max. RF power: | <20 dBm |
Wi-Fi protocol: | 802.11 b/g/n |
Wi-Fi Range: | Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
Bluetooth Protocol: | 4.2 |
Bluetooth Range: | Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
MCU | |
CPU: | ESP32-D0WDQ6 |
Flash: | 16 MB |
FIRMWARE CAPABILITIES | |
Webhooks (URL actions): | 20 with 5 URLs per hook |
Scripting: | mJS |
MQTT: | Yes |
CoAP: | No |
