Lýsing
Stýrikerfismöguleikar: | Linux, Windows |
Vinsluminni (RAM): | 8 GB |
Skjáupplausn: | 1920×1080 |
Stýrikerfi: | Án stýrikerfis. |
Bluetooth: | já |
Chipset: | Intel® TigerLAKE CORE i5 1135 G7 |
Einsatzbereiche: | Indoor |
Litur á skjárönd: | Svart |
Litur á ramma: | Svartur |
HDD stærð: | 128 GB M2 SSD |
IP staðall: | IP 65 |
Myndavél: | Nei |
3G/4G: | Nei |
Aflgjafi: | Fylgir 12V, 5A |
Snertiskjár: | Capacitiv |
WLAN: | 2,4/5 GhZ |
Display Display | |
Screen | 12″ LCD |
Resolution | 1280×800 |
Brightness | 500 cd/m2 |
Contrast | 1000:1 |
Touch Screen | Multi-Point Capacitive touch |
Performance | |
Chipset | Intel® CORE i5 -1135G7 |
RAM | Board 8GB LPDDR4 memory |
Hardware Monitor | Voltage, CPU, TEMP |
Watchdog Timer | Support hardware reset function (256 levels, 0~255 seconds) |
Storage | M.2, 128GB SSD |
Power | |
Power Supply | standard 12V/5A adapter |
Betriebssystem | |
O/S | Windows/Linux not installed (no license) |
I/O Port | |
USB | 2*USB3.0/ 2*USB2.0 |
Ethernet | 4x RJ45 Gigabit network interface |
COM | nicht installiert |
Audio | 1*Line-out, 1*Mic-in |
Display | 1*HD+1*VGA |
Mini PCIE | 1*mini pcie (wifi/bt 2,4/5GHz) |
GPIO | no |
Environmental | |
Anti-vibration | 5-17Hz/1.0mm amplitude; 19-200Hz/1.0g acceleration |
Anti-shock | 10g acceleration, 11ms duration |
IP Level | Front panel IP65 |
Reliability | MTBF=50000h; MTTR=0.5h |
Operating Temperature | minus 10°C – bis +60°C mit Belüftung |
Storage Temperature | -20°C bi +70°C |
Operating Humidity | 95% @40°, non-condensing |
Mechanical | |
Dimensions | |
Mounting size | VESA mounting: 100*100mm Embedded installation: 357mm x 280,5mm |
Material | Fanless High-strength and elegant Al-alloy panel |
Weight | 4.3kg (N.W.) / 4,8kg (G.W) |
Color | Black |
