USW-Lite-Ultra PoE switch - Snjallari lausnir

Lýsing

Nettur, 8-porta, Layer 2 GbE PoE switch frá Unifi með miklum möguleikum til að festa upp.

(7) GbE PoE+ output ports

(1) GbE PoE++ input port

— 42W PoE availability with PoE++ input
— 17W PoE availability with PoE+ input
— 8W PoE availability with PoE input

Max. Power Consumption

9W (Excluding PoE Output) with PoE input

8W (Excluding PoE Output)with adapter input

210W (Including PoE Output) with 210W AC adapter input

Mechanical
Dimensions	202.9 x 76 x 33 mm (8 x 3 x 1.3″)
Weight	Device: 320 g (11.3 oz) Wall mount: 45 g (1.6 oz)
Enclosure material	Polycarbonate
Hardware
Management interface	Ethernet In-Band
Networking interface	(8) GbE RJ45 ports
PoE interface	(7) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput	8 Gbps
Power method	54V, 3.9A power adapter (Not included) PoE++ (Pins 4, 5+; 7, 😎
Power supply	54V, external, 1.1A/60W
Supported voltage range	44—57V DC
Total available PoE	60W PoE++ input: 45W DC adapter input: 52W Passive PoE adapter input: 45W
Max. PoE+ wattage per port by PSE	30W
Button	Factory reset
Operating temperature	-15 to 45° C (5 to 113° F)
Operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
LEDs
System	Status
Ethernet	PoE Link/activity
