Lýsing
Upplifðu óviðjafnanleg þægindi og skilvirkni með snjöllum ofnastilli frá Shelly.
Þörf er á Bluetooth Gateway sem fylgir í pakkanum, hægt að setja í USB hleðslutæki/tölvu.(þarf að vera 5W eða meira)
Hægt er að tengja allt að 5 ofnaloka við eitt Bluetooth-Gateway.
Shelly BLU TRV er snjall ofnhitastillir með Bluetooth tengingu sem tengist við Bluetooth Gateway USB kubb sem fylgir með og gerir ofnlokanum svo kleyft að tengjast við Wi-Fi. Ofnastillirinn stjórnar hitastigi herbergis með því að breyta flæði heita vatnsins í gegnum ofninn. Ef þörf krefur er hægt að breyta hitastigi hvenær sem er með því að snúa á oflokanum til vinstri eða hægri, eða í gegnum farsímann þinn, spjaldtölvuna eða tölvuna. Tækið getur einnig haldið stofuhita í samræmi við ákveðna vikuáætlun. Lokinn er knúinn af 2 AA, 1,5 V rafhlöðum.
-
Bluetooth-operated and Wi-Fi with gateway
-
2×1.5 V battery AA (included)
-
Precise temperature control (adjust by ±0.1 °C)
-
Boost mode for fast warm-up of the room
-
Smart scheduling: Set daily schedules to keep your home warm and save energy
-
External sensor support (compatible with Shelly BLU H&T, Shelly BLU Door/Window sensors, associated via BLU Gateway Gen3)
-
Integration with most smart home systems
-
The gateway can be plugged in any USB power supply, charger or device with a USB-A port (rated at > 5 W)
Properties | |
---|---|
Size (H x W x D): | 60 x 27 x 11 mm / 2.36 x 1.06 x 0.43 inches |
Weight: | 10 g |
Handle material: | Plastic |
Favourite colour: | White |
Environment | |
Environment temperature: | -20 °C to 40 °C |
Humidity: | 30 % to 70 % relative humidity |
Electric | |
Power supply: | 5 V? (via USB-A port) |
Internal consumption of the device: | < 1 W |
Radio | |
WLAN | |
Protocol: | 802.11 b/g/n |
Frequency band: | 2412 – 2472 MHz |
Max. HF power: | < 20 dBm |
Range: | Up to 50 m outdoors, up to 30 m indoors (depending on local conditions) |
Bluetooth | |
Log: | 4.2 with BLE |
Frequency band: | 2402 – 2480 MHz |
Max. HF power: | < 4 dBm |
Range: | Up to 30 m outdoors, up to 10 m indoors (depending on local conditions) |
Microcontroller | |
CPU: | ESP-Shelly-C38F |
Flash: | 8 MB |
Firmware functions | |
Time schedule: | 20 |
Webhooks (URL actions): | 20 with five URLs per hook |
Scripting: | Yes |
MQTT: | Yes |
Encryption: | Yes |
Hvernig skal para ofnastillinn við BLU Gateway ?
